3 tier layer cage
2. Core Specifications: Stocking density 40KG/㎡, corrosion-resistant galvanized iron wire and frame, automatic manure removal, automatic feeding, and automatic watering for modern farms.
3. Technical Support: Provides installation videos and other supporting technical support.
4. Installation Service: On-site installation service available.
5. After-sales Service: 1-year free warranty.
6. Product Advantages: Reduces labor costs and improves farming efficiency; the rational design reduces egg breakage rate and flock injury and disease rate, indirectly improving egg production efficiency and shortening the payback period.
7. Customization available according to customer needs.
3 Tier Layer Cage - Advanced Poultry Farming Solution
Weifang Shuilin Musen's 3 tier layer cage represents a sophisticated vertical housing solution engineered for intensive commercial egg production operations. Manufactured from premium Q235 high-strength galvanized steel wire with hot-dip galvanization, this system delivers a proven service life exceeding 15 years even in high-ammonia environments. Each unit features standardized cell dimensions of 45cm×45cm×450cm with a scientifically calibrated 10° bottom slope for seamless egg roll-out. The H-type integrated three-layer design achieves a density rating of 40KG/㎡, tripling your stocking capacity compared to conventional floor rearing systems. Our layer cage integrates fully automated feeding, watering, and manure removal mechanisms, reducing labor costs by over 40% while maintaining optimal biosecurity standards.
Why Choose Our 3 Tier Layer Cage System?
High land costs and labor shortages challenge today's poultry operations. You need equipment that maximizes every square meter while minimizing operational complexity.
Our system addresses these pain points directly. The vertical stacking design increases your bird capacity by 300% on the same footprint. Automated manure belts eliminate direct fecal contact, cutting ammonia-related respiratory issues and coccidiosis transmission rates significantly.
The egg collection trough features precision engineering. The 10° slope allows gravity-driven egg roll-out without high-velocity impact, reducing breakage rates and preserving product quality. You'll see measurable improvements in both production efficiency and profit margins.
Each tier operates independently. This modular approach lets you scale operations gradually, matching investment pace with cash flow requirements rather than committing to massive upfront capital expenditure.
Technical Specifications
| Parameter | Details |
|---|---|
| Cage Dimensions | 45cm (L) × 45cm (W) × 450cm (H) per unit |
| Stocking Density | 40KG/㎡ |
| Material | Q235 steel wire, hot-dip galvanized |
| Service Life | Over 15 years |
| Cage Bottom Slope | 10° angle for easy egg collection |
| Structure Type | H-type three-layer integrated design |
| Main Components | Cage frame, mesh assembly, egg collection device, feed trough, nipple drinker, water pipe system |
| Compatible Systems | Automatic feeding, automatic watering, automatic manure removal |
| Frame Material | High-strength galvanized steel / 304 stainless steel options |
Key Performance Advantages
Maximized Space Utilization
You gain triple the bird capacity without expanding building footprint. This dramatically lowers your per-bird rental and construction costs, particularly valuable in high-value land markets.
Labor Efficiency Transformation
Integrated automation handles feeding, watering, and waste removal continuously. Your staff shifts from manual repetitive tasks to monitoring and optimization roles, cutting labor requirements by more than 40%.
Superior Biosecurity Standards
Automated manure belts create physical separation between birds and waste. This reduces pathogen exposure, minimizing disease outbreaks and medication costs while improving flock health consistency.
Extended Equipment Longevity
Hot-dip galvanization provides robust corrosion resistance. The Q235 steel construction maintains structural integrity under continuous load, delivering 10-15 years of reliable operation with minimal maintenance.
Enhanced Egg Quality
The scientifically designed collection system reduces handling damage. Eggs roll smoothly into trays, maintaining shell integrity and premium grade classification rates.
Flexible Customization
We adapt dimensions and configurations to your specific facility requirements. Whether retrofitting existing structures or designing new builds, our engineering team develops solutions matching your operational parameters.
Complete System Integration
Our 3 tier layer cage functions as the centerpiece of a fully coordinated production environment.
Feeding System
Automated chain or traveling gantry feeders distribute rations uniformly across all tiers. Programmable timers ensure consistent delivery schedules, optimizing feed conversion ratios and minimizing waste.
Watering Infrastructure
Precision nipple drinkers provide continuous fresh water access. The closed system prevents contamination and spillage, maintaining dry manure conditions that simplify removal and reduce ammonia generation.
Manure Management
Belt-driven removal systems transport waste away from bird zones continuously. You can implement daily or customized removal schedules, maintaining optimal air quality and reducing fly breeding opportunities.
Environmental Control Compatibility
The open framework design facilitates natural ventilation in temperate climates while remaining compatible with powered ventilation and evaporative cooling systems for challenging thermal conditions.
Installation and Support Services
Technical Guidance Package
You receive comprehensive installation videos and detailed technical documentation. Our materials cover foundation preparation, frame assembly, automation integration, and system commissioning procedures.
On-Site Installation Assistance
Our technical team provides hands-on support during setup. We ensure proper alignment, verify automation functionality, and train your personnel on operational protocols and routine maintenance procedures.
12-Month Warranty Coverage
All structural components and integrated systems carry a full one-year warranty. We stand behind our manufacturing quality with rapid replacement of any defective parts and troubleshooting support.
Ongoing Technical Support
Beyond warranty periods, our engineering team remains available for consultation. We assist with capacity expansion planning, automation upgrades, and operational optimization strategies as your business grows.
Frequently Asked Questions
Q: What bird capacity does each unit accommodate?
A: Standard configurations house 90-120 birds per complete three-tier set, with 4-5 birds per individual cell depending on breed size and your target density parameters.
Q: Can the system operate in naturally ventilated buildings?
A: Yes. The A-frame design promotes excellent airflow, making it suitable for open-sided structures in moderate climates without requiring sophisticated HVAC infrastructure.
Q: How does hot-dip galvanization compare to electro-galvanized coating?
A: Hot-dip galvanization applies zinc coating exceeding 275g/m², providing 15-20 year lifespan in ammonia-rich environments. Electro-galvanized alternatives typically corrode within 3 years under similar conditions.
Q: Is partial automation possible initially?
A: Absolutely. The modular design allows you to start with manual or semi-automated feeding and watering, then upgrade to full automation as operational scale and budget permit.
Q: What site preparation does installation require?
A: You need a level concrete floor, structural support for equipment weight distribution, and access for manure removal equipment. Our technical team provides detailed site preparation specifications during planning phases.
Q: Do you accommodate custom dimensions for existing facilities?
A: Yes. We engineer solutions matching your specific spatial constraints, ceiling heights, and operational workflow requirements through our customization service.
Contact Us
Ready to transform your poultry operation? We're here to help.
Reach out to discuss your project, request a quote, or ask technical questions. Our 3 tier layer cage 's team looks forward to partnering with you for farming success.
Email: slms-equipment.com@slms-equipment.com
Let's build a more efficient, profitable future for your farm together.
